%% modified algorithm for stereo disparity block matching
% In this implementation instead of finding shifted image ,indices are mapped accordingly
% to save memory and some processing RGBA column major packed data is used as input for
% Compatibility with CUDA intrinsics Convolution is performed using separable filters (Horizontal and then Vertical)

function [out_disp] = stereoDisparity(img0,img1) %#codegen

% gpu code generation pragma
coder.gpu.kernelfun;

%% Stereo disparity Parameters
% WIN_RAD is the radius of the window to be operated,min_disparity is the minimum disparity level
% the search continues max_disparity is the maximun disparity level the search continues
WIN_RAD = 8;
min_disparity = -16;
max_disparity = 0;

%% Image dimensions for loop control
% The number of channels packed are 4 (RGBA) so as nChannels are 4
[imgHeight,imgWidth]=size(img0);
nChannels = 4;
imgHeight = imgHeight/nChannels;

%% To store the raw differences
diff_img = zeros([imgHeight+2*WIN_RAD,imgWidth+2*WIN_RAD],'int32');

%To store the minimum cost
min_cost = zeros([imgHeight,imgWidth],'int32');
min_cost(:,:) = 99999999;

% Store the final disparity
out_disp = zeros([imgHeight,imgWidth],'int16');

%% Filters for aggregating the differences
% filter_h is the horizontal filter used in separable convolution
% filter_v is the vertical filter used in separable convolution which
% operates on the output of the row convolution
filt_h = ones([1 17],'int32');
filt_v = ones([17 1],'int32');

%% Main Loop that runs for all the disparity levels. This loop is
% expected to run on CPU.
for d=min_disparity:max_disparity

    % Find the difference matrix for the current disparity level. Expect
    % this to generate a Kernel function.
    coder.gpu.kernel;
    for colIdx=1:imgWidth+2*WIN_RAD
        coder.gpu.kernel;
        for rowIdx=1:imgHeight+2*WIN_RAD
            % Row index calculation
            ind_h = rowIdx - WIN_RAD;

            % Column indices calculation for left image
            ind_w1 = colIdx - WIN_RAD;

            % Row indices calculation for right image
            ind_w2 = colIdx + d - WIN_RAD;

            % Border clamping for row Indices
            if ind_h <= 0
                ind_h = 1;
            end
            if ind_h > imgHeight
                ind_h = imgHeight;
            end

            % Border clamping for column indices for left image
            if ind_w1 <= 0
                ind_w1 = 1;
            end
            if ind_w1 > imgWidth
                ind_w1 = imgWidth;
            end

            % Border clamping for column indices for right image
            if ind_w2 <= 0
                ind_w2 = 1;
            end
            if ind_w2 > imgWidth
                ind_w2 = imgWidth;
            end

            % In this step, Sum of absolute Differences is performed
            % across tour channels.
            tDiff = int32(0);
            for chIdx = 1:nChannels
                tDiff = tDiff + abs(int32(img0((ind_h-1)*(nChannels)+chIdx,ind_w1))-int32(img1((ind_h-1)*(nChannels)+chIdx,ind_w2)));
            end

            %Store the SAD cost into a matrix
            diff_img(rowIdx,colIdx) = tDiff;
        end
    end

    % Aggregating the differences using separable convolution. Expect this to generate two Kernel
    % using shared memory.The first kernel is the convolution with the horizontal kernel and second
    % kernel operates on its output the column wise convolution.
    cost_v = conv2(diff_img,filt_h,'valid');
    cost = conv2(cost_v,filt_v,'valid');

    % This part updates the min_cost matrix with by comparing the values
    % with current disparity level.
    for ll=1:imgWidth
        for kk=1:imgHeight
            % load the cost
            temp_cost = int32(cost(kk,ll));

            % compare against the minimum cost available and store the
            % disparity value
            if min_cost(kk,ll) > temp_cost
                min_cost(kk,ll) = temp_cost;
                out_disp(kk,ll) = abs(d) + 8;
            end

        end
    end

end
end
